Model 9000/9100/9500
29
9100 Control Valve Assembly
Item
Quantity
Part Number
Description
1
1
40688
valve body assembly
2
4
15137
screw, hex washer #10-24 x 3/8”
3
1
14906
end plate
4
1
14928
end plug
5
1
19054
O-ring, 124
6
1
18303
O-ring, 336
7
1
40538
retainer, 32mm
8
1
60400
piston top assembly
9
1
60125
seal and spacer kit, top
1
60125-20
seal and spacer kit, top (559PE)
10
1
60421
seal and spacer kit, bottom
1
60421-20
seal and spacer kit, bottom (559PE)
11
1
60401
piston assembly, bottom
12
1
60385-XXXX
injector assembly
(see following chart for dash numbers)
injector
number
DLFC
number
BLFC
number
red #0
00
Blank
0
Blank
0
white #1
01
1.2
1
0.25
1
blue #2
02
1.5
2
0.50
2
yellow #3
03
2.0
3
1.00
3
green #4
04
2.4
4
3.0
5
3.5
6
4.0
7
5.0
8
7.0
9
12A
1
60022-12
brine line flow control assembly, 0.125 gpm
60022-25
brine line flow control assembly, 0.250 gpm
60022-50
brine line flow control assembly, 0.500 gpm
60022-100
brine line flow control assembly, 1.00 gpm
12B
1
60350
brine valve assembly
13
1
61419
distributor adapter kit, 1.05"
Not Shown
14
12763
seal and space stuffer tool
15
13061
spacer puller tool
16
13759
DLFC retainer tool
