9100 electro mechanical timer assembly – Watts PWSTA 90-120K User Manual
Page 12
12
Item
QuantIty
Part number
DescrIPtIon
1
1
13870-03
timer housing assembly.
2
1
17870
label, capacity gallons
3
1
15465
label, Caution
4
1
16930
label, Instruction
5
1
15227
actuator plate
6
1
10300
screw, hex washer #8
7
1
17513
spring clip
8
1
15407
washer, plain #4
9
1
15228
spring
10
1
16270-10
gallon wheel assembly 3/4" standard range meter
16270-50
gallon wheel assembly 3/4" extended range meter
16270-30
gallon wheel assembly 1" standard range meter
16270-40
gallon wheel assembly 1" extended range meter
11
1
13806
program wheel retainer
12
1
13748
screw, flathead #6-20
13
2
11999
button decal
14
1
15223
cycle actuator gear
15
1
13886-01
knob
16
4
13296
screw, hex washer #6-20
17
1
17724
drive pinion
18
1
17723
drive pinion clutch
19
1
14276
spring, meter clutch
20
1
14253
retainer
21
3
14087
insulator
22
1
15314
switch
23
1
15320
switch
24
2
11413
screw, pan head #4-40
25
1
13018
idler shaft
26
1
18563
spring, idler shaft
27
1
13017
idler gear
28
1
13164
drive gear
29
1
13887
motor mounting plate
30
1
18743
motor, 120V 60 Hz.-1/30 RPM
18824
motor, 220V 50 Hz.-1/30 RPM
19170
motor, 120V 60 Hz.-1/15 RPM
18825
motor, 220V 50 Hz.-1/15 RPM
31
2
13278
screw, #6-32
32
1
14265
spring clip
33
1
15055
main drive gear
34
1
19210-02
program wheel, 90 minute
19210-05
program wheel, 180 minute
35
23
15493
roll pin
36
1
15203
harness
37
2
12681
wire nut
38
1
60320-02
auxiliary timer switch kit (not shown)
9100 Electro Mechanical Timer Assembly
