Operation
20
Correcting keystone
Keystoning refers to the situation where the projected image is noticeably wider at either the
top or bottom. It occurs when the projector is not perpendicular to the screen.
To correct this, besides adjusting the height of the
projector, you will need to manually correct it
following ONE of these steps.
1. Press
3 Left/ Right 4 (hot key) on the control
panel of the projector to display the status bar labelled
Keystone. Press
3 Left to correct keystoning at the
top of the image. Press Right
4 to correct keystoning
at the bottom of the image.
2. Press
/
on the remote control to display
the status bar labelled Keystone, then press
to
correct keystoning at the top of the image or press
to correct keystoning at the bottom of the image.
3. Press
6 Menu on the projector or Menu on the remote control. Go to
--> Keystone and adjust the values by pressing
3 Left/ Right 4 on the projector or 3 / 4
on the remote control.
For example,
Selecting a picture mode
The projector is preset with several picture modes so that you can
choose one to suit your program type. To select a operation mode
that suits your need, press Mode. The picture modes available for
different types of signals are shown below.
Refer to page
for more information.
0
Keystone
-6
Keystone
0
Keystone
+6
Keystone
1. Press
3 Left on the projector or
2. Press
on the remote control or
3. Press
3 Left on the projector or 3 on the
remote control when you are in Picture -->
Keystone menu.
1. Press Right
4 on the projector or
2. Press
on the remote control or
3. Press Right
4 on the projector or 4 on
the remote control when you are in Picture -
-> Keystone menu.
PC Signal Input
Presentation (default)
sRGB/Photo
Gaming
Video
YPbPr / S-Video / Video Signal Input
Photo (default)
Movie
Cinema
Gaming
