Bottom side, Connector panel, Bottom side connector panel – BenQ PB6240 User Manual
Page 12
Introduction
8
Bottom side
Connector panel
Refer to page
for more information on making connections to various equipment.
Lamp cover
Front adjuster foot
Rear adjuster foot
Rear adjuster foot
RGB signal input
(PC/ YPbPr/ YCbCr)
socket
RGB signal output
socket & RS232
control port
AC power cord inlet
S-Video socket
USB socket
Audio socket
Video socket
IR remote sensor
