M12 Series Metal Barrel Sensors
Sensing Beam Fixed-Field Models: 680 nm visible red
All Other Models: 660 nm visible red
Supply Voltage and
Current 10 to 30V dc (10% max. ripple) @ 20 mA max current, exclusive of load
Supply Protection
Circuitry Protected against reverse polarity and transient voltages
Output Configuration Complementary (1 normally open and 1 normally closed) solid-state, NPN or PNP, depending on model
Output Ratings 100 mA total across both outputs with overload and short circuit protection
OFF-state leakage current:
ON-state saturation voltage:
NPN: less than 200 µA @ 30V dc (see Application Note 1) NPN: less than 1.6V @ 100 mA
PNP: less than 10 µA @ 30V dc PNP: less than 3.0V @ 100 mA
Output Protection
Circuitry Protected against false pulse on power-up, short-circuit protected
Output Response Time Opposed Mode: 625 microseconds ON/375 microseconds OFF
All Other Modes: 500 µs ON and OFF
NOTE: 100 ms delay on power-up; outputs do not conduct during this time.
Repeatability Opposed Mode: 85 microseconds
All Other Modes: 95 microseconds
Indicators Two Status (yellow) and one Power (green) LED (see Figure 1)
Adjustments Fixed-Field Models: None
All Other Models: Single-turn Gain (sensitivity) potentiometer
Construction Housing: Nickel-plated brass
Lenses: PMMA
Cable Endcap and Gain Potentiometer Adjuster: PBT
Environmental Rating IEC IP67; NEMA 6, IEC IP68 and 1200 PSI Washdown, NEMA ICS 5 Annex F-2002
Connections 2 m (6.5') or 9 m (30') 4-wire PVC-jacketed cable, 4-pin integral Euro-style QD fitting,
or 4-pin 150 mm (6") Euro-style pigtail, depending on model
Operating Conditions Operating temperature: −20° to +60° C (−4° to +140° F)
Relative humidity: 90% max @ +50° C (+122° F) non-condensing
Application Notes 1. NPN off-state leakage current is < 200 μA for load resistances > 3 kΩ or optically isolated loads.
For load current of 100 mA, leakage is < 1% of load current
Certifications
Specifications
