Banner QMT42 Series 400 mm Adjustable Field Sensors - Manual (Page 6)

Banner Engineering Corp., 9714 Tenth Ave. No., Minneapolis, MN 55441 Telephone: (612) 544-3164 FAX (applications) (612) 544-3573
WARRANTY: Banner Engineering Corporation warrants it products to be free from defects for one year. Banner Engineering
Corporation will repair or replace, free of charge, any product of its manufacture found to be defective at the time it is returned
to the factory during the warranty period. This warranty does not cover damage or liability for the improper application of
Banner products. This warranty is in lieu of any other warranty either expressed or implied.
QMT42 Series 400 mm Adjustable Field Sensors
WARNING These photoelectric presence sensors do NOT include the self-checking redundant circuitry
necessary to allow their use in personnel safety applications. A sensor failure or malfunction can result in either
an energized or a de-energized sensor output condition.
Never use these products as sensing devices for personnel protection. Their use as a safety device may create
an unsafe condition which could lead to serious injury or death.
Only MINI-SCREEN ® , MULTI-SCREEN ® , MICRO-SCREEN ™ , MACHINE-GUARD ™ and PERIMETER-GUARD ™ Systems, and other
systems so designated, are designed to meet OSHA and ANSI machine safety standards for point-of-operation guarding
devices. No other Banner sensors or controls are designed to meet these standards, and they must NOT be used as sensing
devices for personnel protection.
!
Mounting Brackets
SMB42L
SMB42U
Model Description
2.3 mm
(0.09 in)
12.7 mm
(0.50 in)
23.3 mm
(0.92 in)
6.4 mm
(0.25 in)
3x 10.0 mm
(0.40 in)
25.4 mm
(1.00 in)
33.0 mm
(1.30 in)
5.0 mm
(0.20 in)
4x M4 x 0.7
2x M3 x 0.5
40.0 mm
(1.58 in)
9.6 mm
(0.38 in)
3.0 mm
(0.12 in)
38.9 mm
(1.53 in)
30.0 mm
(1.18 in)
25.4 mm
(1.00 in)
3.1 mm
(0.12 in)
9.6 mm
(0.38 in)
2x 8.9 mm
(0.35 in)
4x M3 x 0.5
12.7 mm
(0.50 in)
6.5 mm
(0.25 in)
2x M4 x 0.7
12.7 mm
(0.50 in)
23.3 mm
(0.92 in)
2.3 mm
(0.09 in)
25.4 mm
(1.00 in)
3.1 mm
(0.12 in)
• 13 gauge stainless steel
• Hardware included
• 13 gauge stainless steel
• Hardware included
