QMT42 Series 400 mm Adjustable Field Sensors
Banner Engineering Corporation page 5
Quick Disconnect (QD) Cables
M12 x 1
ø15 mm
(0.6 in)
44 mm max.
(1.7 in)
The following is the selection of cables available for the QMT42 QD models
DImensions Style Model Length For use with
4-pin
Euro Style
straight
MQDC-406
MQDC-415
MQDC-430 2 m (6.5 ft)
5 m (15 ft)
9 m (30 ft)
All QMT42 sensors with
quick-disconnect fitting
Pin #2
White Wire
Pin #3
Blue Wire
Pin #4
Black Wire
Pin #1
Brown Wire
Pinout
38 mm max.
(1.5 in)
M12 x 1
ø15 mm
(0.6 in)
38 mm max.
(1.5 in)
4-pin
Euro Style
right-angle
MQDC-406RA
MQDC-415RA
MQDC-430RA 2 m (6.5 ft)
5 m (15 ft)
9 m (30 ft)
Mounting Brackets
SMB19
SMB42F
Model Description
Right-angle, stainless steel,
mounting bracket (M3 mounting
hardware is supplied)
R 5.1 mm
(0.20 in)
ø 3.05 mm
(0.120 in)
ø 3.05 mm Slot
(0.120 in)
20 °
90 °
CL
15 °
(2)
R 24.1 mm
(0.95 in)
31.8 mm
(1.25 in)
20.1 mm
(0.79 in)
45.5 mm
(1.79 in)
20.3 mm
(0.80 in)
R 3.1 mm
(0.12 in) (2)
10 ° (TYP)
4.32 mm
(0.170 in)
Slot (2)
2.5 mm
(0.10 in)
10.0 mm
(0.40 in) 5.0 mm
(0.20 in)
12.7 mm
(0.50 in)
25.4 mm
(1.00 in)
20.0 mm
(0.79 in)
4x M3 x 0.5
2x M4 x 0.7
12.7 mm
(0.50 in)
9.6 mm
(0.38 in)
6.4 mm
(0.25 in)
25.4 mm
(1.00 in)
23.3 mm
(0.92 in)
28.3 mm
(1.12 in)
2.3 mm
(0.09 in)
37.1 mm
(1.46 in)
48.4 mm
(1.91 in)
• 13 gauge stainless steel
• Hardware included
