5-Pin Threaded M12/Euro-Style Cordsets (Single Ended)

Model

Length

Style

Dimensions

Pinout (Female)

MQDC1-506RA

1.83 m (6 ft)

Right-Angle

32 Typ.

[1.26"]

30 Typ.

[1.18"]

ø 14.5 [0.57"]

M12 x 1

MQDC1-515RA

4.57 m (15 ft)

MQDC1-530RA

9.14 m (30 ft)

Mounting Brackets

SMB46L

Right-angle

L bracket

14-ga. 316 stainless

steel

65

54

27

A

Hole center spacing: A = 16.0

Hole size: A = 16.5 x 18.7

SMB46S

Right-angle

S bracket

14-ga. 316 stainless

steel

54

43

65

16

A

B

Hole center spacing: A = 16.0

Hole size: A = 16.5 x 18.7, B = 34.0 x 10.0

SMB46U

Right-angle

U bracket for sensor

protection

14-ga. 316 stainless

steel

70

54

65

16

A

B

Hole center spacing: A = 16.0

Hole size: A = 16.5 x 18.7, B = 34.0 x 13.0

SMB46A

2-piece 12-ga. stainless

steel bracket assembly

with precision sensor

alignment adjustment

2 mm hex key included

Hole center spacing: A to B = 18.5, B = 30.5

Hole size: A = ø 6.6, B = 7.1 x 20.3

SMB46DF

Flat bracket holds two

sensors at a fixed angle

Black anodized

aluminum

114 mm

[4.5"]

57 mm

[2.2"]

60 mm

[2.3"]

37 mm

[1.5"]

18 mm
[0.7"]

1.5 mm

[0.6"]

30 mm

[1.2"]

2 x 32 mm

[1.3"]

21 mm

[0.8"]

2 x ø 18 mm

[0.7"]

2 x R6 mm

[0.2"]

2 x R10 mm

[0.4"]

10 mm

[0.4"]

10 mm

[0.4"]

4 mm
[0.2"]

12 mm
[0.5"]

CL

45 mm

[1.8"]

2 x 3.5 mm
[0.14"] Slot

2 x 15º

PD49 Series Ruggedized PicoDot

®

P/N 67450 Rev. B
