Dimensions – Banner PicoDot PD Series User Manual
Page 5

NPN (Cabled Models)
PNP (Cabled Models)
Wiring Key
Load
Load
3
1
2
4
5
10-30V dc
150 mA
Maximum
each
+ Off
- On
Laser
Control
–
+
(
(
Load
Load
3
1
2
4
5
10–30 V dc
−
+
150 mA
Maximum
each
+ Off
− On
Laser
Control
(
(
1 = Brown
2 = Black
3 = Blue
4 = White
5 = Gray
Dimensions
PicoDot
®
PD49VP6C50
bn
bu
+
10-30V dc
150 mA
Maximum
Load
+ OFF
- ON
–
bk
wh
gy
LOAD
LOAD
Laser
Control
PicoDot
®
PD49VP6C50
bn
bu
+
10-30V dc
150 mA
Maximum
Load
+ OFF
- ON
–
bk
wh
gy
LOAD
LOAD
Laser
Control
49.1 mm
(1.93")
42.7 mm
(1.68")
10.4 mm
(0.41")
15.2 mm
(0.60")
6.9 mm
(0.27")
5.1 mm
(0.20")
37.0 mm
(1.46")
32.0 mm
(1.26")
5.0 mm
(0.20")
37.3 mm
(1.47")
30.9 mm
(1.22")
6.3 mm
(0.25")
11.8 mm
(0.47")
Sensitivity
Adjustment
Signal Indicator
Power Indicator
M3 (#4) Screw Clearance (2x)
C'sink opposite side (2x): 6.2 mm (0.25") dia.
1.8 mm (0.07") deep
Mounting hardware included with Sensor (2) Each:
M3 x 0.05 20 mm SS Cap Screws
M3 Hex Nuts
M3 Lock Washers
M3Flat Washers
Emitter Axis
PD49 Series Ruggedized PicoDot
®
P/N 67450 Rev. B
www.bannerengineering.com - tel: 763-544-3164
5
