Banner WORLD-BEAM QS18 Standard Series - Manual (Page 2)

Convergent Mode Model Range Output
630 nm Visible Red
QS18VN6CV15
16 mm (0.63 ft)
NPN
QS18VP6CV15 PNP
QS18VN6CV45
43 mm (1.7
inches)
NPN
QS18VP6CV45 PNP
Diffuse Mode Model Range Output
940 nm Infrared QS18VN6D
450 mm (18
inches)
NPN
QS18VP6D PNP
QS18VN6DB (Diffuse, wide) NPN
QS18VP6DB (Diffuse, wide) PNP
Divergent Mode Model Range Output
940 nm Infrared QS18VN6W
100 mm (4
inches)
NPN
QS18VP6W PNP
Fixed Field Mode Model Range Output
660 nm Visible Red
QS18VN6FF50
50 mm (2 inches)
NPN
QS18VP6FF50 PNP
QS18VN6FF100
100 mm (4
inches)
NPN
QS18VP6FF100 PNP
Plastic Fiber Optic Mode Model Range Output
660 nm Visible Red QS18VN6FP
Range varies by sensing
mode and fiber optics
used
NPN
QS18VP6FP PNP
Glass Fiber Optic Mode Model Range Output
940 nm Infrared QS18VN6F
Range varies by sensing
mode and fiber optics
used
NPN
QS18VP6F PNP
WORLD-BEAM QS18
2 www.bannerengineering.com - tel: 763-544-3164 P/N 63908 Rev. H
