Banner Q45 Series User Manual
Q45vr2 series sensors, Datasheet

Datasheet
•
Advanced one-piece photoelectric sensors with outstanding optical performance
and extremely rugged design
•
Operate from 90 to 250 V ac (50/60 Hz)
•
SPDT electromechanical relay output for economical, high-capacity switching
and immunity to electrical noise
•
Multiple sensing modes include: opposed, diffuse, retroreflective, and
convergent, plus glass and plastic fiber optic models
•
Switchable light/dark operate
•
Versatile plug-in modules available for output timing logic and/or signal
strength display
•
Highly visible Power, Signal (AID
™
System
1
), and Output indicator LEDs
•
Choice of prewired 2 m (6.5 ft) or 9 m (30 ft) unterminated cable or Mini-style
quick-disconnect fitting
•
Versatile mounting options
•
Designed to withstand 1200 psi washdown; exceeds its NEMA 6P and IEC IP67
rating
WARNING: Not To Be Used for Personnel Protection
Never use this device as a sensing device for personnel protection. Doing so could lead to
serious injury or death. This device does not include the self-checking redundant circuitry necessary
to allow its use in personnel safety applications. A sensor failure or malfunction can cause either an
energized or de-energized sensor output condition.
Opposed-Mode Emitter (E) and Receiver (R) Models
Because of their extremely high excess gain, these opposed-mode sensors are an excellent option
for sensing in contaminated or dirty areas, and are also the best choice for long-range sensing.
Range: 60 m (200 ft)
Output Type: SPDT Electro-mechanical relay
Effective Beam: 13 mm
OPPOSED
Infrared, 880 nm
Models
Cable
Excess Gain
Beam Pattern
Q452E Emitter
2-wire 2 m (6.5 ft) cable
1
10
100
1.0 m
3.3 ft
10 m
33 ft
100 m
330 ft
0.1 m
0.33 ft
E
X
C
E
S
S
G
A
I
N
DISTANCE
1000
Q45E/R
Opposed Mode
48 m
160 ft
60 m
200 ft
36 m
120 ft
24 m
80 ft
12 m
40 ft
0
0
0.5 m
1.0 m
1.5 m
0.5 m
1.0 m
1.5 m
0
20 in
40 in
60 in
20 in
40 in
60 in
DISTANCE
Q45E/R
Opposed Mode
Q45VR2R Receiver
5-wire 2 m (6.5 ft) cable
Q452EQ Emitter
3-Pin Mini-style QD
Q45VR2RQ Receiver
5-Pin Mini-style QD
To order the 9 m (30 ft) cable model, add suffix "W/30" to the cabled model number. (For example: Q452E W/30.) Models
with a QD connector require a mating cable.
1 U.S. Patent no. 4356393
Q45VR2 Series Sensors
P/N 36339 Rev. F
14 January 2014
