S2 Series
Dimension Information
Hookup Information
78.7 mm
(3.10")
Yellow LED
Output Indicator
37.0 mm
(1.46")
Jam Nuts
(2 Provided)
18 x 1 mm
Thread
Green LED
Power
Indicator
Yellow LED
Output Indicator
Green LED
Power Indicator
Jam Nuts
(2 Provided)
M30 x 1.5
Thread
77.5 mm
(3.05")
53.0 mm
(2.09")
25.0 mm
(0.98")
35.0 mm
(1.38")
30.0 mm*
(1.18")
12.4 mm
(0.49")
(Jam Nut Supplied)
Lens Centerline
15.2 mm
(0.60")
M18 x 1 Thread
Green LED
Power Indicator
Yellow LED
Output Indicator
12.7 mm
(0.50")
40.1 mm
(1.58")
50.0 mm
(1.97")
46.0 mm
(1.81")
20.1 mm
(0.79")
(Jam Nut Supplied)
Lens Centerline
19.8 mm
(0.78")
M30 x 1.5 Thread
Green LED
Power Indicator
Yellow LED
Output Indicator
82.5 mm
(3.25")
Jam Nut
(2 Supplied)
11.5 mm
(0.45")
M30 x 1.5
Thread
ø15 mm
(0.59")
ø40.0 mm
(1.57")
45.0 mm
(1.77")
66.5 mm
(2.62")
Green LED
Power Indicator
Yellow LED
Output Indicator
Jam Nut
(Supplied)
11.5 mm
(0.45")
M18 x 1
Thread
ø15 mm
(0.59")
30.0 mm
(1.18")
56.6 mm
(2.23")
ø30.0 mm
(1.18")
Green LED
Power Indicator
Yellow LED
Output Indicator
S18 S30
Q25 Q40
T18 T30
+10 to 30V dc
(Brown wire)
Sensing output
(Black wire)
DC common
(Blue wire)
Alarm
(White wire)
Quick Disconnect Pin Detail
connector on sensor shown (male pins)
+10 to 30V dc
(Brown wire)
DC common
(Blue wire) Not used
(Black wire)
Not used
(White wire)
Emitter Quick Disconnect Pin Detail
connector on sensor shown (male pins)
Note: Wire colors are for Banner MQDC-4 Series quick disconnect cables
