MINI-BEAM ® Sensors
SM312LV, SM312LVAG and SM312LP
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Mounting Brackets
46.0 mm
(1.81 in)
44.5 mm
(1.75 in)
36.0 mm
(1.42 in)
2.5 mm
(0.10 in)
25.4 mm
(1.00 in)
13.0 mm (0.50 in)
Nut Plate
Spacer
(If Required)
M5 x 0.8
x 60 mm
Screw (2)
6.4 mm
(0.25 in)
10.9 mm
(0.43 in)
SMB18S
• 18 mm swivel, black thermoplastic polyester
bracket
• Stainless steel mounting hardware included
Model Description
R 5.1 mm
(0.20 in)
ø 4.6 mm
(0.18 in)
ø 4.6 mm Slot
(0.18 in)
20 °
90 °
CL
15 °
(2)
R 24.1 mm
(0.95 in)
31.8 mm
(1.25 in)
40.6 mm
(1.60 in)
45.5 mm
(1.79 in)
18.42 mm
(0.725 in)
R 3.1 mm
(0.12 in) (2)
15.2 mm
(0.60 in)
2.5 mm
(0.10 in)
Dimensions
SMB312PD • Stainless steel 18 mm barrel-mounting bracket
40.0 mm
(1.60 in)
42.4 mm
(1.67 in)
30.0 mm
(1.18 in)
2.5 mm
(0.10 in)
21.1 mm
(0.83 in)
Nut Plate
M5 x 0.8
x 60 mm
Screw (2)
13 mm
(0.5 in)
14.0 mm
(0.55 in)
SMB18C
• 18 mm split clamp black thermoplastic
polyester bracket
• Stainless steel mounting hardware included
