8.2 Method listings
44
824 Easy Sample Changer, Annex
8.2.3 Method 3
824 Easy Sample Chan. 5.824.0010 ¬ Report header with program version
parameters
method 3 ¬ Method name
number of samples: rack ¬ No. of samples (whole sample rack)
>start sequence
1 CTL:Rm: INIT ¬ Initialize remote interface
2 SAMPLE: - 1 ¬ Initialize
3 SAMPLE: + 1 sample position
>sample sequence
1 SHIFTRATE: + 20 ¬ Rack direction of rotation (clockwise)
2 MOVE 1 : sample ¬ Move next sample in front of tower
3 LIFT: 1 : work mm ¬ Move lift to working position
4 STIR: * : ON s ¬ Switch on stirrer
5 CTL:Rm: START dos* ¬ Start addition
6 WAIT 10 s ¬ Waiting time
7 CTL:Rm: START device1 ¬ Start instrument/titrator
8 SCN:Rm : End1 ¬ Wait for end of determination [EOD]
9 STIR: * : OFF s ¬ Switch off stirrer
10 LIFT: 1 : rinse mm ¬ Move lift to rinsing position
11 WAIT 3 s ¬ Waiting time: 3 s for drips
12 PUMP 1.1 : 3 s ¬ Switch on pump, 3 s for rinsing
13 WAIT 3 s ¬ Waiting time: 3 s for drips
>final sequence
1 MOVE 1 : spec.1 ¬ Move rinsing beaker in front of tower
2 LIFT: 1 : work mm ¬ Immerse electrode
>changer settings ------ Sample changer settings --------
rack number 0
lift rate 1 25 mm/s
shift rate 20
shift direction: auto.
beaker test mode: single ¬ If sample beaker is missing then the
on beaker error: MOVE next one will be moved to automatically
>stirring rates ------ Stirring rates ---------------------------
stirrer 1 3
stirrer 2 3
>manual stop ------ Reaction to manual stop --------------
CTL Rmt: STOP device1 ¬ Stop instrument/titrator
CTL RS232:
