4 Appendix
822 Titration Curve Simulator, Instructions for Use
15
SER_OUT - bit 11: MOT_INFO
MOT_INFO = L:
MOT_INFO = H:
Definition of the signals
SER_OUT bit 5 ... 10, 15 ... 17
Information about current
speed of the spindle motor
(MOT_D0…SN) and cock
position (ISTPOS0…2)
Information of the digital inputs
IN0…2, NHWR, NPOR, OVERL,
EXP0…2
SER_OUT - bit 12: BUSY Status message for active cock
switching
SER_OUT - bit 13: STOP_O Driver stage spindle or cock
motor inactive
SER_OUT - bit 14: ESM End switch middle
SER_OUT - bit 15: ISTPOS0/EXP0 Bit 0 for cock position or coding
the cylinder volume
SER_OUT - bit 16: ISTPOS1/EXP1 Bit 1 for cock position or coding
the cylinder volume
SER_OUT - bit 17: ISTPOS2/EXP2 Bit 2 for cock position or coding
the cylinder volume
SER_OUT - bit 18: DOS_TYP0 Bit 0 definition of the chip
function
SER_OUT - bit 19: DOS_TYP1 Bit 1 definition of the chip
function (formerly "GTYP")
SER_OUT - bit 20: DOS_TYP2 Bit 2 definition of the chip
function
SER_OUT - bit 21: DOS_TYP3 Bit 3 definition of the chip
function
SER_OUT - bit 22: P10000 Bit 0 for stating the number of
pulses for the total volume
SER_OUT - bit 23: P20000 Bit 1 for stating the number of
pulses for the total volume
SER_OUT - bit 24: PWR Enables "Hot Plug & Play" of
the device and recognize
temporally unusual supply and
control data
Commands for dosing device:
SER_IN - bit 0:
UP Filling impulses for spindle
motor
SER_IN - bit 1: DOWN Dosing impulses for spindle
motor
SER_IN - bit 2: R_NRW Use data or set STROBE
impulse
