1.2 Rear View
717 Sample Changer, Overview 2
The Connectors (side view):
Remote
Control 1 2 3 4
The remote socket serves the connection of Metrohm- or other
measuring instruments that communicate via a serial cable.
1.2 Rear View
Made by Metrohm Herisau Switzerland
Type 1.717._
Address
External Bus 0020/02 187
Remote
socket Stirrer
sockets
Guide chain
Mounting screw
for splash protection
Pump 1
Pump 2
Valves
Plug cover
Connectors
Distribution head
