5.1 Technical Specifications

717 Sample Changer, Appendix

5 Appendix

Appendix

5.1 Technical Specifications

5.1.1 717 Sample Changer

Dimensions

Height: 0.72 m, Width: 0.28 m, Depth: 0.48 m

Weight

15.5 kg (without accessories, 2-tower model)
10.0 kg (without accessories, 1-tower model)

Material

Sample Changer case:

metal case, multiple enameling

Lift path

235 mm

Lift

Load:

approx. 10 N

Stroke speed: adjustable, 3 – 25 mm/s

Turntable

Turning speed:
adjustable, 3 – 20 angular degrees/s

Stirrer

Stirring speed: adjustable to 15 levels
- Magnet stirrer 180/s – 2600/s
- Rod stirrer 180/s – 3000/s

Pump with

Conveying capacity (manometric lift 2m):

Valve

0.33 L/min
