3 Installation
902 Titrando
￭￭￭￭￭￭￭￭ 23
NOTE
The electrode cable is protected against accidental disconnection
of the cable by means of a pull-out protection. If you wish to pull
out the plug again, you will first need to pull back the outer plug
sleeve.
3.5.2 Connecting a reference electrode
Connect the reference electrode as follows:
1 Plug the electrode plug into the Ref. socket of the 902 Titrando.
Figure 13 Connecting a reference electrode
3.5.3 Connecting a temperature sensor or an electrode with integrated
temperature sensor
A temperature sensor of the Pt1000 or NTC type can be connected to the
Temp. connector.
Connect the temperature sensor or the electrode with integrated temper-
ature sensor as follows:
1 Insert the plugs of the temperature sensor into the Temp. sockets of
the Titrando.
Figure 14 Connecting a temperature sensor or an electrode with
integrated temperature sensor
