©2013-2014 DJI. All Rights Reserved.35 |
8 Appendix
8.1 Specifications
Aircraft
Operating environment temperature -10 ℃ to 50℃
Power consumption 5.6W
Supported Battery DJI Intelligent battery
Weight (including the battery) 1000g
Take-off Weight ≤1300g
Hovering Accuracy (Ready to Fly) Vertical: 0.8m; Horizontal: 2.5m
Max Yaw Angular Velocity 200°/s
Max Tilt Angle 35°
Max Ascent / Descent Speed Ascent: 6m/s; Descent: 2m/s
Max Flight Speed 15m/s (Not Recommended)
Wheelbase 350mm
2.4GHz Remote Control
Operating Frequency 2.4GHz ISM
Communication Distance (open area) 1000m
Receiver Sensitivity (1%PER) -97dBm
Working Current/Voltage 120 [email protected]
Built-in LiPo Battery Working Current/Capacity 3.7V, 2000mAh
DJI Intelligent Battery
Type 3S LiPo Battery
Capacity 5200mAh, 11.1V
Charging Environment Range 0 ℃ to 40℃
Discharging Environment Range -20 ℃ to 50℃
8.2 LED Flight Indicators Description
Aircraft in Normal status Descriptions
Power On Self-Test
Warming Up & Aircraft cannot take off during warming up
Ready to Fly
Ready to Fly (non-GPS)
Aircraft in abnormal status Warnings and errors
Remote Control Signal Lost
1 st Level Low Battery Capacity Warning
