BIOS and pre-OS video for configuration and imaging,
Continued
Create session
and view video The table below shows how to create a PCoIP session to view pre-OS video.
Step Action
1 Press the power button on the front of the blade to power it on, and then press the
power button on the front of the zero client to power it on.
2 From a monitor connected to the zero client, click the Connect button.
Result: After several moments the zero client identifies host cards to which it can
connect. The zero client on-screen display (OSD) lists one or more host card IP
addresses and their corresponding MAC addresses.
NOTE: The video host card MAC address is specified on a label on the side of
the blade.
3 Select the blade’s host card from the list and click OK.
Result: The zero client and blade establish a PCoIP session displaying the blade’s
desktop.
4 Reset blade power from the operating system Start menu or by pressing the reset
button on the front of the blade. Watch monitors for pre-OS video (for example, a
message to press the F2 key for configuration screens) and press the appropriate key.
5 After performing configuration steps, power off both devices. Remove the blade and
zero client power cables from the power outlets and then remove the cables from
each device.
6 Remove all peripherals from both devices.
7 Replace the blade in the chassis as described previously.
Next steps: You can now deploy the A6106D blade. See the documentation shown below for
important details about A6106D configuration, operation, and maintenance.
