Introduction
About this
guide This quick start guide shows the components and features of the A6106D blade and explains
how to install and remove the blade from an A-series chassis. The guide explains how to
view pre-OS video (if required) and provides references to additional information about
A6106D blades, A-series chassis, and to information about using PCoIP
® technology.
A6106D
overview A6106D blades are 6U high, single-slot blades that mount in an A3100 chassis. The A3100
chassis provides power, network interface, and USB ports for each blade.
The picture below shows zero clients connected to A6106 blades in an A3100 chassis.
Figure 2. An example deployment of A6106D blades and zero clients
A3100 Chassis
A6106D Blade
WAN/LAN
PCoIP
Zero Clients
