Page 6, Figure 2: the rear connections – Blizzard Lighting EM-Pulse LED Strobe Fixture User Manual
Page 6
Page 6
EM-Pulse User Manual - Rev. A
(c) 2014 Blizzard Lighting, LLC
Figure 1: The EM-Pulse™ Pin-Up Picture
1,452 Bright
White LEDs
Durable Cast
Aluminum Housing
Natural Convection
Heat Sink Cooling
Figure 2: The Rear Connections
AC Power In
3/5-Pin
DMX512 In
3/5-Pin
DMX512 Out
Mounting Bracket
Locking
Knobs
AC Power Out
Easy-To-Use 4-Button
LCD Control Panel
