EM-Pulse User Manual - Rev. A

4. OPERATING ADJUSTMENTS

The Control Panel

All the goodies and different modes possible with the EM-Pulse™ are

accessed by using the control panel on the front of the fixture. There

are 4 control buttons below the LCD display which allow you to navi-

gate through the various control panel menus.

Button

Function

Used to access the menu or return to a previous menu option.

Scrolls through menu options in descending order.

Scrolls through menu options in ascending order.

Used to store the current menu or option within a menu.

The LCD control panel display shows the menu items you select from

the menu map on page #11. When a menu function is selected, the

display will show immediately the first available option for the selected

menu function. To select a menu item, press .

To navigate through the LCD control panel, use the

buttons to scroll through the menu options. Press the button,

then use the buttons to view any sub-menu options.

Press to continue without saving, or press button,

then the to save and return to the previous menu item.
