EM-Pulse User Manual - Rev. A (c) 2014 Blizzard Lighting, LLC
DMX Values In-Depth (16-Channel Mode)
Ch. Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Segment 1-3 Intensity (0% <--> 100%)
3 000 <--> 255 Segment 4-6 Intensity (0% <--> 100%)
4 000 <--> 255 Segment 7-9 Intensity (0% <--> 100%)
5 000 <--> 255 Flash Duration (0% <--> 100%)
6 000 <--> 255 Strobe Rate (0-30Hz)
7
000 <--> 005
006 <--> 042
043 <--> 085
086 <--> 128
129 <--> 171
172 <--> 214
215 <--> 255
Built-In Programs
No function
Ramp up effect (slow <--> fast)
Ramp down effect (slow <--> fast)
Ramp up-down effect (slow <--> fast)
Random effect (slow <--> fast)
Lightning effect (slow <--> fast)
Spike effect
8 000 <--> 255 Segment 1 Intensity (0-100%)
9 000 <--> 255 Segment 2 Intensity (0-100%)
10 000 <--> 255 Segment 3 Intensity (0-100%)
11 000 <--> 255 Segment 4 Intensity (0-100%)
12 000 <--> 255 Segment 5 Intensity (0-100%)
13 000 <--> 255 Segment 6 Intensity (0-100%)
14 000 <--> 255 Segment 7 Intensity (0-100%)
15 000 <--> 255 Segment 8 Intensity (0-100%)
16 000 <--> 255 Segment 9 Intensity (0-100%)
DMX Values In-Depth (7-Channel Mode)
Ch. Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Segment 1-3 Intensity (0% <--> 100%)
3 000 <--> 255 Segment 4-6 Intensity (0% <--> 100%)
4 000 <--> 255 Segment 7-9 Intensity (0% <--> 100%)
5 000 <--> 255 Flash Duration (0% <--> 100%)
6 000 <--> 255 Strobe Rate (0-30Hz)
7
000 <--> 005
006 <--> 042
043 <--> 085
086 <--> 128
129 <--> 171
172 <--> 214
215 <--> 255
Built-In Programs
No function
Ramp up effect (slow <--> fast)
Ramp down effect (slow <--> fast)
Ramp up-down effect (slow <--> fast)
Random effect (slow <--> fast)
Lightning effect (slow <--> fast)
Spike effect
