EM-Pulse User Manual - Rev. A
(c) 2014 Blizzard Lighting, LLC
2. MEET THE EM-PULSE™ LED STROBE FIXTURE
MAIN FEATURES
• Super bright output via 1,452 white SMD LEDs
• Intense built-in strobe programs + random strobe
• 3/9-segment pixel modes can safely be used as wash (max 40% brightness)
• Built-in over heat protection temperature sensor to extend the lamp life
• Variable electronic strobe & 16-bit dimmer
• User adjustable flash rate of 0-30 flashes per second
• Flash duration can be set from 0-650ms in DMX mode
• 7000Hz LED scan rate
• 4-button easy to use LCD control panel menu
• Aluminum mounting bracket with locking knobs + base plate
• 3-pin & 5-pin DMX Input/Output
• PowerCon™ compatible AC power In/Out connectors
DMX Quick Reference (1/3/4/6/7/16-Channel Modes)
Channel Mode
What it does
1
3
4
6
7
16
---
1
1
1
1
1
Master Dimmer (0-100%)
---
---
---
2
2
2
Segment 1-3 Intensity (0-100%)
---
---
---
3
3
3
Segment 4-6 Intensity (0-100%)
---
---
---
4
4
4
Segment 7-9 Intensity (0-100%)
---
2
2
5
5
5
Flash duration (0-full on)
1
3
3
6
6
6
Strobe rate (0-30Hz)
---
---
4
---
7
7
Built-In Effects
---
---
---
---
---
8
Segment 1 Intensity (0-100%)
---
---
---
---
---
9
Segment 2 Intensity (0-100%)
---
---
---
---
---
10
Segment 3 Intensity (0-100%)
---
---
---
---
---
11
Segment 4 Intensity (0-100%)
---
---
---
---
---
12
Segment 5 Intensity (0-100%)
---
---
---
---
---
13
Segment 6 Intensity (0-100%)
---
---
---
---
---
14
Segment 7 Intensity (0-100%)
---
---
---
---
---
15
Segment 8 Intensity (0-100%)
---
---
---
---
---
16
Segment 9 Intensity (0-100%)
DMX Quick Reference (3/9-Channel: Pixel Modes)
3-Channel Pixel Mode
9-Channel Pixel Mode
1
Segment 1-3 Intensity (0-100%)
Segment 1 Intensity (0-100%)
2
Segment 4-6 Intensity (0-100%)
Segment 2 Intensity (0-100%)
3
Segment 7-9 Intensity (0-100%)
Segment 3 Intensity (0-100%)
4
---
Segment 4 Intensity (0-100%)
5
---
Segment 5 Intensity (0-100%)
6
---
Segment 6 Intensity (0-100%)
7
---
Segment 7 Intensity (0-100%)
8
---
Segment 8 Intensity (0-100%)
9
---
Segment 9 Intensity (0-100%)
