Bird BA–300/310 Blower Assembly
8
Load Resistor
To connect the Blower Assembly to a load, follow these instructions:
y
Remove one of the vertical panels by unscrewing both 10-32 truss
head screws.
y
Place the load on the blower assembly against the remaining
vertical panel. Be sure that the RF input connector faces the same
direction as the blower control panel.
y
Line up the base holes and loosely screw the load and blower
together with the nuts and screws provided.
y
Remount the side panel and loosely replace the truss head screws.
y
Line up the holes on the side panel tabs with those on the front
and rear faces of the load. Secure with four 10-32 truss head
screws.
+
NOTE: It may be necessary to temporarily loosen the two screws
in the unremoved vertical panel.
y
Tighten all the side panel and base mounting screws securely.
y
Push the power cable’s plug into the socket at the rear of the
blower, then lock it in place with the clamp.
AC Power Hookup
The ac power supply required is 115/230 Vac, depending on the
model, @ 50/60 Hz, 1
φ
. The blower is equipped with an IEC 320 “cold”
(65 °C) ac inlet.
WARNING
Disconnect the unit from all power sources before servicing.
The unit may be energized from multiple sources.
The potential for electric shock exists.
WARNING
Do not operate with side panel removed.
CAUTION
Check the local electrical code for proper ac hookup prior to
operation of the unit. Make sure the neutral or return hookup is
only used for that purpose.
WARNING
Turn off ac power and RF power when attaching the power cable.
