44
7.1.4 Q: What additional diagnostic information is available?
A: The external LED part # K075866 is connected via the cable harness as a
separate plug. Please refer to Section C, 4.0, step 7 for details on installation
and location of this LED. The LED functions as described in the table below.
Flashing with pattern will have periods of 0.3 second on and 0.3 second off
repeating every 6 seconds. The number of high pulses in each 6–second
window will be determined by a code. For example if the flash code is 2, the
pattern will be 0.3 second on, 0.3 second off, 0.3 second on, 5.1 seconds
off and repeating.
Alarms Priority External LED See
Note
No Alarms 0 Off -
Second Level Low Pressure (SAL) 6 Pattern flashing
code: 4
-
SAL Cleared 0 Off -
First Level High Pressure (FAL_H) 4 Pattern flashing
code: 2
-
First Level Low Pressure (FAL_L) 3 Pattern flashing
code: 2
-
FAL Cleared 0 Off -
High Temperature 7 Pattern flashing
code: 5
-
High Temperature Cleared 0 Off -
Sensor Diagnostic Trouble Code (DTC) Set 2 Pattern flashing
code: 1
1
Sensor DTC Cleared 0 Off -
ROM To Both Copy Performed 10 Pattern flashing
code: 7
2
Set Up DTC 5 Pattern flashing
code: 3
3
Set Up DTC Cleared 0 Off -
Factory To Custom Copy Performed 9 Pattern flashing
code: 7
2
Custom To Factory Copy Performed 8 Pattern flashing
code: 7
4
Watchdog Reset 11 Pattern flashing
code: 8
5
Sensor Battery Low Alert 1 Pattern flashing
code: 6
-
Table 5
