Bendix Commercial Vehicle Systems TABS-6 ADVANCED SINGLE CHANNEL - Manual (Page 15)

15
Diagnostic Trouble Codes
(DTCs)
(continued)
1st
Digit
2nd
Digit
Diagnostic
Code
Description
Possible Causes / Repair Information
J1587
(SID/
FMI)
J1939
(SPN/
FMI)
Trailer System Braking
9 1
Extended Brake
Application
Detected
• Verify that there is no residual pressure in the trailer’s control (service)
line.
• After repairs or if no issues are found, then clear the diagnostic codes.
• If diagnostic code persists:
‑ Contact the BCVS local representative before replacing the TABS-6
Advanced module.
057/07 1047/07
9 2
Excessive ABS
Activity Detected
Dynamic Wheel Speed Sensor DTC - possible incorrect wheel speed
signal while vehicle in motion resulted in long ABS event.
Go to Section E on Page 31.
057/07 1047/07
9 3
Excessive TRSP
Activity Detected
• Clear diagnostic codes.
• If diagnostic code persists:
‑ Contact the BCVS local representative before replacing the TABS-6
Advanced module.
057/07 1047/07
TABS‑6 Advanced Module (TABS‑6 Adv)
10 1
TABS‑6
Advanced
Internal Error
• Check for damaged or corroded connectors.
• Check for damaged wiring.
• After repairs or if no issues are found, then clear the diagnostic codes.
• If diagnostic code persists:
‑ Contact the BCVS local representative before replacing the TABS-6
Advanced module.
254/12 629/12
10 2
TABS‑6
Advanced
Configuration
Error
• Verify the ECU parameters and actual system installation is compatible
using the Bendix ® ACom ® Diagnostic Software (version 6.1 or higher).
• Re-program ECU as necessary.
• If necessary, contact the BCVS local representative to obtain the correct
configuration data.
254/13 629/13
10 3
TABS‑6
Advanced
EEPROM Error
• Verify the ECU parameters and actual system installation is compatible
using the Bendix ® ACom ® Diagnostic Software (version 6.1 or higher).
• Re-program ECU as necessary.
• If necessary, contact the BCVS local representative to obtain the correct
configuration data.
254/13 629/13
10 4
TABS‑6
Advanced Not
Configured
• Re-program the ECU to be compatible to the actual system configuration
using the Bendix ® ACom ® Diagnostic Software (version 6.1 or higher).
• If necessary, contact the BCVS local representative to obtain the correct
configuration data.
254/13 629/13
10 5
TABS‑6
Advanced
EOL Test Not
Completed
• Perform the Installation Test using the Bendix ® ACom ® Diagnostic
Software (version 6.1 or higher), or Trailer Information Module.
254/14 629/14
Auxiliary Design Language (ADL) & Auxiliary I/O’s
11 1
TABS‑6
Advanced
Auxiliary I/O
Error:
AUX I/O #7
(Trailer ABS
Indicator Lamp)
• Check for corroded/damaged wiring or connectors between the ECU and
the ABS Indicator Lamp.
• Check Pin X1-5 of the ECU ‘Power’ connector for the following:
‑ Pin not pushed back.
- Correctly wired to the ABS Indicator Lamp (Pin X1-5 – supply).
- Shorted to ground, Vbat or other ECU pins.
• Verify the ABS Indicator Lamp is properly grounded and not burnt out.
• After repairs or if no issues are found, then clear the diagnostic codes.
• If diagnostic code persists, contact the BCVS local representative before
replacing the TABS‑6 Advanced module.
152/12 612/12
