Setup Menu Diagram
When entering a menu, the active parameter setting is highlighted.
MAIN DISPLAY, showing time code, frame rate, sync rate, jam mode, network channel, battery status
↓ push select switch down to enter main menu and to select opƟons, toggle left/right to navigate
↓
GEN
↓ JamTC ↔ Edit ↔ Offset
↓
JamTC: AUTO ↔ OFF ↔ manual/once
↓
Edit: HH:MM:SS:FF
↓
Offset: +/- 00.05 frames
↓
UB JamUB ↔ Edit-UB ↔ EXIT ↓
JamUB: normal ↔ manual ↔ insert
Edit-UB: 00:00:00:FF
EXIT: back to main menu
↓
SYNC
↓ PPF ↔ OFF
↓
PPF: 1x ↔ 2x ↔ 4x ↓ HIGH ↔ LOW
↓
OFF: NO SYNC OUTPUT
↓
TC
↓ FPS ↔ MTC ↔ Level
↓
FPS FPS: 23.976 ↔ 24 ↔ 25 ↔ 29.97 ↔ 30 ↔ 29.97D ↔ 30D
↓
MTC MTCout ↔ MIDI>LTC ↔ LTC>MIDI
↓
Level TC level Lemo/TC: 0 dB to -45 dB
↓
SYS
↓ Config ↔ INFO ↔ Factory reset
↓
Display ↔ Lemo/ACN ↔ BAT
↓
Display: Brightness: 0…↔5↔…10 ↓ AutoOff: never ↔ 5sec ↔ … ↔ 5min
↓
Lemo/ACN: USB: MTC ↔ COM
↓
BAT Battery type: Li ↔ Alk ↔ NiMH
↓
INFO: displays device information: serial no., firmware version, mac address
↓
Factory Reset: loads default settings
