2. Installation
The Trusted TM 20 Channel Isolated AI/DI FTA T8834 is designed to be mounted on either of the TS32
or TS35 DIN rails in the horizontal or vertical positions as required. The location of the connectors on
the FTA are shown in Figure 3.
Figure 2 Connector locations
3. Associated Cable Selection
Refer to the Product Descriptions detailed below:
PD-TC600 Trusted TM I/O SmartSlot Cables 60-Channel
PD-TC700 Trusted TM I/O Companion Slot Cables 60-Channel
NOTE
60 channel cables are used for this FTA due to the three wire per channel connection to the input
module.
CON1
DIN41612
TB1 Screw Terminals
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
TB2 Screw Terminals
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Channel 1
Circuit Channel 5
Circuit
Channel 2
Circuit
Channel 3
Circuit
Channel 4
Circuit
Channel 6
Circuit
Channel 7
Circuit
Channel 8
Circuit
Channel 9
Circuit
Channel 10
Circuit
Channel 11
Circuit
Channel 12
Circuit
Channel 13
Circuit
Channel 14
Circuit
Channel 15
Circuit
Channel 16
Circuit
Channel 17
Circuit
Channel 18
Circuit
Channel 19
Circuit
Channel 20
Circuit
TB3 Screw Terminals
