Trusted
TM
Fibre TX RX Unit T8314
Issue 10 Sep 08
PD-T8314
9
2. Installation
The Trusted
TM
Fibre TX/RX Unit T8314 may be mounted on either of the TS32 or TS35 DIN rails in the
horizontal or vertical position as required.
Note: Allow a minimum of 200mm on either side of the Unit to allow for the fibre cable bend radius.
This bend radius may vary depending upon the type of cable chosen by the user.
3. Associated Trusted
TM
Cable Selection
Cable Type
Description
TC-302-01
250 Mbits/s Remote Expander Outgoing Cable from T8312 to T8314
TC-303-01
250 Mbits/s Remote Expander Incoming Cable from T8314 to T8310
Table 1 Associated Trusted
TM
Cable Selection
Note: ICS Triplex recommends that BICC Brand-Rex Helios Optical Single Mode Fibre Cable be
used to inter-connect the Trusted
TM
Fibre TX/RX Units. The cable must be configured using
‘SC’ type connectors.
