4 MD60 / MD65 OIM Quick Reference
Menu Navigation Tabs
Parameter List
Table 2 – Menu Navigation Tabs
Tabs Description
DIAG The Diagnostics tab is used for displaying faults, the device
(drive or peripheral) status and version.
PARAM The Parameter tab is used for parameter editing. Parameters
can be displayed in groups, in a linear list, or only those
changed from their defaults.
DSEL The Device Select tab is used to select the device (drive or
peripheral) the OIM is to access.
MEM The Memory Storage tab is used for OIM CopyCat (uploading/
downloading configurations to the OIM EEPROM).
OIM The OIM Setup Tab is used to access OIM parameters, view
the OIM version, and to edit the Reference text when a user-
defined Reference is used.
Table 3 – OIM Parameter List
No. Name and Description Details
001 (Startup Display) - Selects the display screen
shown when the OIM is powered up.
Default;
Values:
Type:
0 = Main Menu
0 = Main Menu
1 = Process Disp
2 = Large Disp
3 = StartupParam
Read/Write
002 (Startup Param) - Selects the parameter to be
displayed if parameter 001 (Startup Display) is
set to 3 “Startup Param”.
Default:
Minimum:
Maximum:
Type: 1
1
65535
Read/Write
003 Reserved
004 (User Disp Line 1) - Selects the parameter to
display on User Display Line 1 of the Process
Display screen. For example, setting to 3
selects parameter D003 (Output Current) on
an MD60 drive.
Default:
Minimum:
Maximum:
Type: 3
1
65535
Read/Write
005 (User Disp Line 2) - Selects the parameter to
display on User Display Line 2 of the Process
Display screen. For example, setting to 5
selects parameter D005 (DC Bus Voltage) on
an MD60 drive.
Default:
Minimum:
Maximum:
Type: 5
1
65535
Read/Write
