Safety considerations, Specifications – Rockwell Automation T71xx Regent+Plus Processor Modules 110 VAC, 220/240VAC and 24VDC User Manual
Page 13

Processor Modules (T7110, 11, 12, 20, 21, and 22)
P D - 7 0 0 0 S e p - 0 4 (Issue 1)
1 3
Safety Considerations
Processor module catalog numbers T7110, T7112, T7120 and
T7122 are TÜV certified for Risk Class 5 safety critical
applications. Catalog numbers T7111 and T7121 (220 VAC
powered modules) have not been certified as they do not meet the
DIN VDE 0110 requirements for creepage and clearances.
Specifications
Voltage Range
T7110/T7120:
T7111/T7121:
T7112/T7122:
85 to 132 VAC
170 to 263 VAC
20 to 30 VDC
Frequency Range
T7110/T7120:
T7111/T7121:
T7112/T7122:
47 to 63 Hz
47 to 63 Hz
—
Maximum Load
100 VA
Fusing
2 A, 250 V, slo blo (3AG),
(located on controller chassis)
Use with Chassis
T7110/T7120:
T7111/T7121:
T7112/T7122:
T7100
T7101
T7102
Power Hold-Up Time
10 msec, minimum
Heat Dissipation
46 Watts, 156 BTUs/hour
Fault Contact Rating
(Class II Connection Only)
Load Current (max.):
Load
(min.):
Voltage
(max.):
Switching
Capacity
(max.):
1 amp
10 mV, 0.1 mA
30 VAC, 42.5 VDC
30 VA, 42.5 VAC (resistive)
Memory Size
128K:
512K:
T7110, T7111, T7112
T7120, T7121, T7122
Memory Type
Battery-backed CMOS RAM
