Specifications – Rockwell Automation 1440-TB-D XM-943 Expansion Relay Terminal Base User Manual
Page 16
16 XM-943 Expansion Relay Terminal Base
Publication
GMSI10-IN023A-EN-P - May 2010
Specifications
The following table lists the technical specifications for the XM-943
Expansion Relay Terminal Base.
Note: Power specification is with module installed.
Product Feature
Specification
Power
Module
Consumption
Heat Production
+21.6 to +26.4V dc
120mA maximum
2.9 Watts (9.9 BTU/Hr) maximum
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
Conformal Coating
-20 to +65°C (-4 to +149°F)
-40 to +85°C (-40 to +185°F)
95% non-condensing
All printed circuit boards are conformally coated in
accordance with IPC-A-610C.
Physical
Dimensions
Terminal Screw Torque
3.875 W x 3.75 D x 2.25 H inches
9.48 W x 9.53 D x 5.72 H centimeters
7 pound-inches (0.6 Nm)
