1-4 Parallel Gate Amplifier
1.3 Related Publications
This manual provides a description of each component of the Parallel Gate Amplifier
system as well as installation guidelines. Note that this instruction manual does not
describe specific applications of the standard hardware.
Additional information about using the Parallel Gate Amplifier as part of an AutoMax
Distributed Power System is found in the instruction manuals, prints, and other
documents shipped with each drive system. Always consult the prints shipped with the
drive system for specific mounting and connecting information about your drive.
The other instruction manuals located in binder S-3000, Distributed Power System DC
Drive, are listed in table 1.2. It is assumed that the user is familiar with these other
manuals in S-3000 before using the PGA system.
Table 1.2 – DPS Documentation
Document Part Number
Document SD/SF3000 Binder S-3000
DPS Overview S-3005
UDC Module S-3007
Fiber-Optic Cabling S-3009
Configuration and Programming S-3006 (for SD3000)
S-3036 (for SF3000)
Power Module Interface Rack and Modules S-3008
Diagnostics, Troubleshooting, and Startup Guidelines S-3011
Information Guide S-3012
