24Vdc Digital Input FTA Non-Incendive T8805
Issue 1 Aug 08
PD-T8805
10
4.2. PL1 Connections
Pin
Service
1
24V-1V
2
0V
3
0V
4
24V-2
Table 2 PL1 Connections
4.3. PL2 Connections
Pin
Service
1
Channel 1 24V dc to field device
2
Channel 1 return signal from field device
3
Channel 2 24V dc to field device
4
Channel 2 return signal from field device
5
Channel 3 24V dc to field device
6
Channel 3 return signal from field device
7
Channel 4 24V dc to field device
8
Channel 4 return signal from field device
9
Channel 5 24V dc to field device
10
Channel 5 return signal from field device
11
Channel 6 24V dc to field device
12
Channel 6 return signal from field device
Table 3 PL2 Connections
4.4. PL3 Connections
Pin
Service
1
Channel 7 24V dc to field device
2
Channel 7 return signal from field device
3
Channel 8 24V dc to field device
4
Channel 8 return signal from field device
5
Channel 9 24V dc to field device
6
Channel 9 return signal from field device
7
Channel 10 24V dc to field device
8
Channel 10 return signal from field device
9
Channel 11 24V dc to field device
10
Channel 11 return signal from field device
11
Channel 12 24V dc to field device
12
Channel 12 return signal from field device
Table 4 PL3 Connections
