Rockwell Automation TAI16AIR 16-Channel Analogue Input Termination Card User Manual
Page 9
TAI16AIR October 2005 – Issue 5
9
Triguard SC300E TAI16AIR 16-Channel A/I Termination Card
SUPPLEMENTARY INFORMATION
DIN Connector J1 pins
Function
+ve
-ve
Common field supply negative
1a
Cable screen to chassis backplane earth
1c
Ch1
2a
2c
Ch2
4a
4c
Ch3
6a
6c
Ch4
8a
8c
Ch5
10a
10c
Ch6
12a
12c
Ch7
14a
14c
Ch8
16a
16c
Ch9
18a
18c
Ch10
20a
20c
Ch11
22a
22c
Ch12
24a
24c
Ch13
26a
26c
Ch14
28a
28c
Ch15
30a
30c
Ch15
32a
32c
