SDS-8017
Trusted
TM Industrial Control System
Trusted TM Peer to Peer Communications - T8017
ICS Triplex
Technical data sheets are intended for
information and guidance. The Company
has a policy of continual product
development and improvement.
Specifications are subject to change
without notice. For latest information, visit
our Website:-
www.icstriplex.com
BLOCK DIAGRAM
ELECTRICAL SPECIFICATION
No. of Peer Networks per
System <4
Target Inter-application
Response
Single point change nx15ms + 2x(source + destination
application scan)
All points change nx15ms + (per 1000 digital points per
node) +nx15ms + (per 60 analogue
points per node) +2x(source
+destination application scan)
n=no. of nodes/systems on the network
Points per Network 40000 digital
20000 analogue
No. of Nodes per Network 2
Points per node/System Peer Communication points are to be
included in the total number of external
points. Each point is equivalent to a
single I/O point. The total I/O point
count must remain within the Trusted
TM
IEC1131 TOOLSET constraints.
MECHANICAL,
ELECTRICAL AND
ENVIRONMENTAL
SPSECIFICATION
The Peer to Peer
Communications employs
the Trusted
TM
Communications Interface.
Refer to the corresponding
product information for
further details of the
electrical, mechanical and
environmental
specifications.
