SDS-8200
Trusted
TM Industrial Control System
Trusted TM High Integrity Power Supply-T8200
ICS Triplex
Technical data sheets are intended for
information and guidance. The Company
has a policy of continual product
development and improvement.
Specifications are subject to change
without notice. For latest information, visit
our Website:-
www.icstriplex.com
ELECTRICAL SPECIFICATION
Voltage Range
T8220, T8223, T8224, T8225
T8222, T8226
85V ac to 264V ac
20V dc to 30V dc
Frequency Range
T8220, T8223, T8224, T8225 47Hz to 63Hz
Inrush Current
T8220, T8223, T8224, T8225
20/40A (peak) Cold, 35/65A (peak) Hot
Power Factor 0.95min
Efficiency 70%
Use With Chassis
T8220, T8223, T8224, T8225
T8222, T8226
T8200
T8202
Fusing (internal to module)
T8220, T8222, T8224
T8223, T8225, T8226
6A, 250V, 3AG Slow Blow
20A, 250V 3AG Slow Blow
Output Voltage
T8220, T8223, T8224, T8225
T8222, T8226
+15V dc
+24V dc
Output Power 250W per module
Power Hold-up Time
T8220, T8223, T8224, T8225
T8222, T8226
20ms minimum
1ms minimum
MECHANICAL
SPECIFICATION
Dimensions (HxWxD):
266mm x 483mm x
343mm
(10.47ins x 19ins x
13.5ins)
Weight (fully populated)
26.5kg (approx.)
(58.4lbs approx.)
ENVIRONMENTAL
Operating Temperature:
-5
°C to 60°C
(23 °F to 140°F)
Operating Humidity:
5 to 95%, non-
condensing
Vibration:
10 to 57Hz
±0.075mm
57 to 150Hz 1g
Shock:
15g, ½ sine wave, 11ms
EMI (IEC 801):
ESD
Air discharge to 15kV
Contact discharge to 8kV
Radiated Fields
10V/m, 27MHz to
500MHz
Transients and Bursts
2kV, 2.5kHz for
t=60 seconds
