Trusted
TM
Analogue Input FTA Non Incendive T8835
Issue 1 Aug 08
PD-T8835
11
4.5. PL4 Connections
Pin
Service
1
Channel 13 24V dc to field device
2
Channel 13 return signal from field device
3
Channel 14 24V dc to field device
4
Channel 14 return signal from field device
5
Channel 15 24V dc to field device
6
Channel 15 return signal from field device
7
Channel 16 24V dc to field device
8
Channel 16 return signal from field device
9
Channel 17 24V dc to field device
10
Channel 17 return signal from field device
11
Channel 18 24V dc to field device
12
Channel 18 return signal from field device
Table 5 PL4 Connections
4.6. PL5 Connections
Pin
Service
1
Channel 19 24V dc to field device
2
Channel 19 return signal from field device
3
Channel 20 24V dc to field device
4
Channel 20 return signal from field device
5
Channel 21 24V dc to field device
6
Channel 21 return signal from field device
7
Channel 22 24V dc to field device
8
Channel 22 return signal from field device
9
Channel 23 24V dc to field device
10
Channel 23 return signal from field device
11
Channel 24 24V dc to field device
12
Channel 24 return signal from field device
Table 6 PL5 Connections
