3.1.2. Conditioning Unit Specification
The following specification applies to all signal conditioning unit types
.
Operating Voltage Range
15 to 30V dc
Power consumption
2W max
Operating Temperature
-40
o
C to +85
o
C
Common mode Isolation
1500V rms
Continuous field voltage withstand
120V rms
Accuracy
+/- 0.3% span
Output Signal range
+1 to +5V
3.1.3. Available Conditioning Units
Input Types
Range
Model Number (A) Model Number (B)
0 to +10mV
7B30-01-1
SCM7B30-01
0 to +100mV
7B30-02-1
SCM7B30-02
0 to +1V
7B30-03-1
SCM7B30-03
+1 to +5V
7B30-05-1
SCM7B30-04
-10mV to +10mV
7B30-06-1
SCM7B30-05
-100mV to +100mV
7B30-07-1
SCM7B30-06
-1V to +1V
7B30-08-1
SCM7B30-07
0 to 10V
Not available
SCM7B30-08
-5 to +5V
Not available
SCM7B31-01
-10 to +10V
Not available
SCM7B31-02
Isolated Voltage
0 to 5V
Not available
SCM7B31-03
4 to 20mA
7B32-01-1
SCM7B32-01
Isolated Current
0 to 20mA
Not available
SCM7B32-02
-100 to +100
o
C (-148 to +212
o
F)
7B34-01-1
SCM7B34-01
0 to +100
o
C (+32 to +212
o
F)
7B34-02-1
SCM7B34-02
0 to +200
o
C (+32 to +392
o
F)
7B34-03-1
SCM7B34-03
0 to +600
o
C (+32 to +1112
o
F)
7B34-04-1
SCM7B34-04
Isolated RTD
Pt 100ohm
Linearized
-50 to +350
o
C (-58 to +662
o
F)
7B34-05-1
SCM7B34-05
0 to +300
o
C (+32 to +572
o
F)
7B34-N-01-1
SCM7B34N-01
Isolated RTD
Ni 120ohm
Linearized
0 to +200
o
C (+32 to +392
o
F)
7B34-N-02-1
SCM7B34N-02
Isolated 2 wire
Transmitter
(inc loop power)
4 to 20mA
7B35-01-1
SCM7B35-01
