Programming Basics 3-3
Note the following when using the keypad:
• If you were viewing a display (d) parameter when power
was last removed from the drive, the same display
parameter value will reappear when the drive is
re-powered.
If you were viewing any other parameter value (A, b, or C)
when power was removed, the parameter group or
parameter number will appear when the drive is
re-powered.
• When viewing parameters within the A, b, and C groups,
the parameters will wrap from A01 through C91 by
pressing
▲ or ▼ . To view parameters within the d and F
groups, press PROGram until the display shows A - -, b - -
or C- -. Once the group letter is displayed, use
▲ or ▼ to
scroll to the d and F parameters.
Table 3.1 – Key Descriptions
Key Description
• Toggles between parameter number and
parameter value.
• Selects the parameter group or individual
parameter.
• Scrolls through parameters or parameter groups.
• Increases or decreases parameter values.
Enters the displayed value into memory.
When the Start key is active, starts the motor in the
direction of rotation defined in F04 [
START KEY
DIRECTION ].
• Stops the motor.
• Clears drive faults.
P R O G
