Operating envelope – Rockwell Automation T3446H ICS Regent Relay Output Modules User Manual
Page 10
Relay Output Modules (T3446L, H)
1 0
Industrial Control Services
Figure 5. Jumper Locations.
Operating Envelope
Figure 6 shows the voltage and current operating envelopes
for the T3446L and T3446H. The T3446L relays are initially
gold clad and have an initial resistance of 50 mOhm
maximum. However, operation at high voltages and currents
will remove the gold and the closed resistance will increase
substantially. This increased resistance reduces its ability to
subsequently switch very low power loads.
