15 in. mounting cutout – Rockwell Automation 6185-F RAC6185 Industrial Flat Panel Monitors Quick Start User Manual
Page 2
15 in. Mounting Cutout
Découpe de montage pour le 15 pouces • 15-Zoll-Einbauausschnitt • Corte de montajede 15 pulg. • Taglio di Montaggio per versione da 15 pollici • 15 pol. Recorte de Montagem
401.574
[15.81]
381.000
[15.00]
254.000
[10.00]
127.000
[5.00]
20.574
[0.81]
29.718
[1.17]
101.600
[4.00]
16 x 7.112
[0.28]
177.800
[7.00]
279.400
[11.00]
309.118
[12.17]
12.700
[0.50]
406.400
[16.00]
322.580
[12.70]
8.128
[0.32]
Publication 6185-QS001A-MU-P - July, 2002
41061-194-01(1)
