Kinetix 6000M Hybrid Coupler Cable 7
Publication 2090-IN038B-EN-P - March 2012
Specifications
Additional specifications for each cable are available in the Kinetix ® Motion Accessories
Technical Data, publication GMC-TD004 .
Additional Resources
These documents contain additional information concerning related products from Rockwell
Automation.
You can view or download publications at http://www.rockwellautomation.com/literature .
To order paper copies of technical documentation, contact your Allen-Bradley
® distributor or
Rockwell Automation ® sales representative.
Attribute 2090-CCPP8S8
Wire sizes:
DC Bus (650V DC)
Control Power (42V DC)
Communication (CAN, Safety, SYSOK) 12 AWG
16 AWG
22 AWG
Diameter of cable
(1)
(1) Cable diameter tolerance is ± 0.13 mm (0.005 in.).
14.2 mm (0.56 in.)
Bend radius of cable 170 mm (6.70 in.)
O-ring expansion period One minute between
disconnection and reconnection.
Resource Description
Kinetix 6000M Integrated Drive-Motor User Manual,
publication
2094-UM003
Information on installing, configuring, starting, and
troubleshooting a Kinetix 6000M integrated drive-motor
system.
Kinetix 6000M Integrated Drive-Motor Installation
Instructions, publication
MDF-IN001
Information on the installation of your Kinetix 6000M
integrated drive-motor unit.
Allen-Bradley Industrial Automation Glossary, publication
AG-7.1
A glossary of industrial automation terms and abbreviations.
System Design for Control of Electrical Noise Reference
Manual, publication
GMC-RM001
Information, examples, and techniques designed to minimize
system failures caused by electrical noise.
Kinetix Rotary Motion Specifications Technical Data,
publication
GMC-TD001
Catalog numbers and product specifications, including
performance, environmental, certifications, load force, and
dimension drawings for Allen-Bradley rotary products.
Kinetix Motion Accessories Technical Data, publication
GMC-TD004
Catalog numbers and product specifications, including
performance, environmental, certifications, and dimension
drawings for Allen-Bradley accessories.
