Mount the panelview 300 micro terminal – Rockwell Automation 2711-NR12K DTAM-E to PanelView 300 Micro Adapter Plate User Manual
Page 4

4 DTAM-E (Bulletin 1747) to PanelView 300 Micro (Bulletin 2711) Adapter Plate
Publication 2711-IN052A-EN-P - March 2007
3. Position the adapter plate in the panel or enclosure mounting hole.
The adapter plate mounting studs fit into the existing DTAM-E mounting
holes.
See Product Dimensions on page 5.
4. Install the nuts and alternately tighten the nuts to a torque of 1.13 Nm
(10 lb-in).
Mount the PanelView 300 Micro Terminal
The following instructions provide panel cutout dimensions for the PanelView 300
Micro terminal in an existing enclosure for the DTAM-E terminal.
The PanelView 300 Micro terminal mounts in the adapter cutout. When it is
properly installed, the faceplate provides a NEMA Type 4 rating. Follow these steps
to install the PanelView 300 Micro terminal.
1. Remove the four mounting nuts from the hardware bag provided with the
product.
2. Position the PanelView 300 Micro terminal in the adapter plate.
3. Install the nuts and alternately tighten the nuts to a torque of 1.13 Nm
(10 lb-in).
TIP
The adapter plate and unit have mounting gaskets preinstalled. You need to
press them against the enclosure before installing the nuts.
