Português, Descrição, Conteúdo do pacote – Rockwell Automation 2711P-RAK4 Cutout Adapter Kit for PVPlus 400 Keypad and 600 TouchTerminals User Manual
Page 33: Ferramentas necessárias, Kit adaptador de corte
Publicação 2711P-IN020A-MU-P
Instruções de Instalação
Kit Adaptador de Corte
para Terminal PanelView Plus 400 Keypad / 600 Touch
Código de catálogo 2711P-RAK4
Português
Descrição
Este documento fornece instruções sobre como montar um terminal PanelView Plus 400
Keypad ou 600 Touch usando uma placa adaptadora em um corte de PanelView Standard 550
Keypad existente.
Conteúdo do pacote
O Kit Adaptador de Corte inclui:
• placa adaptadora de corte com junta
• 6 porcas #8-32 com arruelas de pressão
Ferramentas necessárias
As seguintes ferramentas são necessárias para a instalação:
• chave para soquete com soquete de 11/32 polegadas
• chave de torque com capacidade para 12 pol-lb (1,36 N•m)
