Rockwell Automation 2711P-RVT12 Solar Visor Accessory User Manual
Page 10
10 Accessorio parasole
Publication 2711P-IN025C-MU-P - March 2007
5. Inserire le clip nei fori e fissarle con due dadi autobloccanti M4 forniti.
Stringere con una coppia di 1,13 Nm (10 poll.-lb). Vedere l'illustrazione di
sotto per il corretto orientamento delle clip.
6. Fare scorrere il parasole verso il basso.
Le clip mantengono il parasole in posizione.
Parasole
Clip parasole
Dadi autobloccanti
