RAC6000 Celeron “Socket 370” CPU Passive Backplane Processor Board
RAC6000 Products 6155 processor options DK, FK
Manufacturer Trenton Technology Inc.
Model name CBI, number 5721-005-xM (xM = memory)
Technical Manual shipped with product
Processor and PC System
•
Intel Celeron 433MHz (Socket 370)
•
Intel Pentium II 440BX Chip Set with AGP interface
•
66MHz system/memory bus speed
•
64-bit DRAM/Memory
•
32-bit PCI Bus, 33MHz bus speed
•
16-bit ISA Bus, 8MHz bus speed
•
PCI Plug and Play Compatible
Memory
•
128K Level 2 Cache Memory, integrated on Celeron.
•
Up to 512MB of Synchronous DRAM (SDRAM) Memory
•
66MHz industry standard 64-bit (non-ECC) or 72-bit (ECC) wide gold contact DIMM DRAM
•
Two 168-pin DIMM sockets
•
DRAM error checking and correction (ECC) support – BIOS selectable
•
Current shipping options:
32MB option – one 4Mx72 DIMM 64MB option – one 8Mx72 DIMM
128MB option – one 16Mx72 DIMM 256MB option – two 16Mx72 DIMM
On-Board Ports and Connections
•
Accelerated Graphics Port (AGP) Super VGA Video Port (HD15 connector)
•
AGP interface with 2MB on-chip display memory
•
supports resolutions of 1280x1024 non-interlaced and 16.8 million colors up to 1024x768
•
PCI 10/100Base-T Ethernet Port (RJ-45 connector)
•
Intel 82559 interface
•
IEEE 802.3 and PCI Local Bus 2.1 compliant
•
2 serial ports (DB9 connectors)
•
1 parallel port (DB25 connector)
•
PS/2 mouse and AT style keyboard (mini DIN connectors)
•
2 Universal Serial Bus (USB) 1.0 ports
Hardware Diagnostics Support
•
System Hardware Monitor (board temperature, system voltages)
•
Watchdog Timer
•
Power Fail Detection
BIOS
•
AMIBIOS; Ver. RACCBI04.ROM
•
Advanced CMOS setup for system parameters, peripheral management for configuring on-board
peripherals, PCI-to-PCI bridge support, PCI interrupt steering
•
Flash EEPROM memory for easy BIOS field upgrade
•
Shadow RAM for System BIOS and peripherals to increase system speed and performance
