Voltage Sensing Board – Instruction Sheet
A T T E N T I O N
A T T E N T I O N
Resistors are fragile and are susceptible to
damage from improper handling. As a result,
resistors should be tested after installation.
Failure to verify proper functioning of the
resistors before commissioning the SMC may
result in injury to personnel or damage to
equipment.
The Voltage Sensing Board is pre-installed on MV SMC OEM
frames (items 7703E-FRxx). Refer to MV SMC Flex OEM
Components – Bulletin 7703E, Installation Instructions
(Publication 7703E-IN001_-EN-P) for complete installation
instructions of the Voltage Sensing Board.
Additional Publications
To order additional copies of Instruction Manuals for all Rockwell
Automation medium voltage products, please contact a Rockwell
Automation sales office or your local distributor.
Medium Voltage Products, 135 Dundas Street, Cambridge, ON, N1R 5X1 Canada, Tel: (1) 519.740.4100, Fax: (1) 519.623.8930, www.ab.com/mvb
Publication 7703E-IN006A-EN-E – May 2008
Copyright © 2008 Rockwell Automation, Inc. All rights reserved. Printed in Canada.
